LAG3 ELISA Kit

Catalog No. ABIN8055936

This Colorimetric ELISA kit is designed for the quantitative measurement of Human LAG3.

Quick Overview for LAG3 ELISA Kit (ABIN8055936)

Target: LAG3 (Lymphocyte-Activation Gene 3 (LAG3))

Reactivity: Human

Detection Method: Colorimetric

Method Type: Sandwich ELISA

Detection Range: 93.8 pg/mL - 6000 pg/mL

Application: ELISA

Sample Type: Cell Culture Supernatant, Plasma (EDTA), Plasma (heparin), Serum

Product Details LAG3 ELISA Kit

Minimum Detection Limit: 93.8 pg/mL

Purpose: Sandwich Human LAG-3 ELISA Kit to quantitate Human LAG-3 in cell culture supernatants, serum, plasma(heparin, EDTA).

Analytical Method: Quantitative

Specificity:

Capture antibody and Detection antibody: polyclonal antibody from goat|polyclonal antibody from goat

Cross-Reactivity (Details): There is no detectable cross-reactivity with other relevant proteins.

Sensitivity: < 15 pg/mL

Components:

1. Pre-coated 96-well strip microplate
2. Standard
3. Biotinylated antibody (100x)
4. Avidin-Biotin-Peroxidase Complex (100x)
5. Sample Diluent
6. Antibody Diluent
7. Avidin-Biotin-Peroxidase Diluent
8. Color Developing Reagent (TMB)
9. Stop Solution
10. Wash Buffer (25x)
11. Adhesive plate sealers

Material not included: Microplate Reader capable of reading absorbance at 450nm. Incubator. Automated plate washer (optional). Pipettes and pipette tips capable of precisely dispensing 0.5 μL through 1 mL volumes of aqueous solutions. Multichannel pipettes are recommended for large amount of samples. Deionized or distilled water. 500 mL graduated cylinders. Test tubes for dilution.

Application Details

Application Notes: Before using Kit, spin tubes and bring down all components to bottom of tube. Duplicate well assay was recommended for both standard and sample testing.

Sample Volume: 100 μL

Plate: Pre-coated

Protocol: ELISA Kit is based on standard sandwich enzyme-linked immune-sorbent assay technology. An antibody has been precoated onto 96-well plates. Standards and test samples are added to the wells, a biotinylated detection antibody specific for target is added subsequently and then followed by washing with PBS or TBS buffer. Avidin-Biotin-Peroxidase Complex was added and unbound conjugates were washed away with PBS or TBS buffer. HRP substrate TMB was used to visualize HRP enzymatic reaction. TMB was catalyzed by HRP to produce a blue color product that changed into yellow after adding acidic stop solution. The density of yellow is proportional to the target amount in sample captured in plate.

Assay Precision: Intra-Assay Precision (CV%): 2.9%, 2.7%, 4.3%
Inter-Assay Precision (CV%): 7.4%, 4.0%, 3.9%

Restrictions: For Research Use only

Handling

Handling Advice: Avoid multiple freeze-thaw cycles.

Storage: 4 °C,-20 °C

Storage Comment: Store at 4°C for 6 months, at -20°C for 12 months. Avoid multiple freeze-thaw cycles (Ships with gel ice, can store for up to 3 days in room temperature. Freeze upon receiving.)

Expiry Date: 12 months

Target Details for LAG3

Target: LAG3 (Lymphocyte-Activation Gene 3 (LAG3))

Alternative Name: LAG3

Background:

Background: Lymphocyte-activation gene 3, also known as LAG-3, is a protein which in humans is encoded by the LAG3 gene. Lymphocyte-activation protein 3 belongs to Ig superfamily and contains 4 extracellular Ig-like domains. The LAG3 gene contains 8 exons. The sequence data, exon/intron organization, and chromosomal localization all indicate a close relationship of LAG3 to CD4.

Gene Full Name: lymphocyte activating 3

Gene ID: 3902

UniProt: P18627

Pathways: Regulation of Leukocyte Mediated Immunity, Positive Regulation of Immune Effector Process, Cancer Immune Checkpoints
