Collagen IV antibody

Catalog No. ABIN5596835

Product Details anti-Collagen IV Antibody

Target: Collagen IV (COL4) (Collagen, Type IV (COL4))

Reactivity: Human, Cow, Mammalian

Host: Rabbit

Clonality: Polyclonal

Conjugate: This Collagen IV antibody is un-conjugated

Application: ELISA, Western Blotting (WB), Immunohistochemistry (IHC), Immunoprecipitation (IP)

Cross-Reactivity (Details): Typically negligible cross-reactivity against other types of collagens was detected by ELISA against purified standards. Some class-specific anti-collagens may be specific for three-dimensional epitopes which may result in diminished reactivity with denatured collagen or formalin-fixed, paraffin embedded tissues. This antibody reacts with most mammalian Type IV collagens and has negligible cross-reactivity with Type I, II, III, V or VI collagens. Non-specific cross-reaction of anti-collagen antibodies with other human serum proteins or non-collagen extracellular matrix proteins is negligible.

Purification: Anti-Collagen Type IV has been prepared by immunoaffinity chromatography using immobilized antigens followed by extensive cross-adsorption against other collagens, human serum proteins and non-collagen extracellular matrix proteins to remove any unwanted specificities.

Immunogen:

Immunogen: Collagen Type IV from human and bovine placenta

Immunogen Type: Native Protein

Isotype: IgG

Product Specific Information:

What can the Collagen 4 antibody ABIN5596835 be used for? This polyclonal collagen 4 antibody is unconjugated and has been validated for ELISA, IHC, IP and western blotting. Native collagen type 4 from human and bovine placenta was used as immunogen for the production of the COL4 antibody.

What validation data is available for this Collagen 4 antibody? The antibody has been referenced in 8 Pubmed publications to date and is characterized by high reliability. The references are given below. 9 images show the performance of the product in different applications.

What is the function of Collagen 4? Collagen type 4 is the major structural component of glomerular basement membranes, forming a 'chicken-wire' meshwork together with laminins, proteoglycans and entactin/nidogen. (Uniprot). The collagen 4 protein consists of an amino-terminal 7S domain, a triple-helix forming collagenous domain, and a carboxy-terminal non-collagenous domain. It functions as part of a heterotrimer and interacts with other extracellular matrix components such as perlecans, proteoglycans, and laminins. (NCBI)

Application Details

Application Notes:

Immunohistochemistry Dilution: 1:50 - 1:200

Application Note: Anti-Collagen antibodies have been used for indirect trapping ELISA for quantitation of antigen in serum using a standard curve, immunoprecipitation, native (non-denaturing, non-dissociating) PAGE, immunohistochemistry, and western blotting for highly sensitive qualitative analysis.

Western Blot Dilution: 1:1,000 - 1:10,000

Immunoprecipitation Dilution: 1:100

ELISA Dilution: 1:5,000 - 1:50,000

Restrictions: For Research Use only

Independent Validation (IHC)

Validation #300049 (Immunohistochemistry)

by: MS Validated Antibodies

No.: #300049

Date: 08/07/2023

Antigen: COL4

Lot Number: 48011

Method validated: Immunohistochemistry

Positive Control:

Human TMA

Recombinant rabbit anti-COL4 antibody (MSVA-704R)

Notes:

Passed. Staining of collagen type IV using ABIN5596835 is consistent with the expected staining pattern.

Validation Images

IHC staining of lung tissue with anti-collagen IV antibody ABIN5596835 diluted 1:200 shows staining of basement membranes and vessels.

IHC staining skeletal muscle tissue with anti-collagen IV antibody ABIN5596835 diluted 1:200 shows collagen IV fibres surrounding skeletal muscle cells.

IHC staining of renal oncocytoma tissue with anti-collagen IV antibody ABIN5596835 diluted 1:300 shows dense collagen IV-positive membranes surrounding tumor cell nests.

Full Methods

Primary Antibody: ABIN5596835

Secondary Antibody: EnVision Polymer-HRP mouse/rabbit Kit, Dako REAL, K5007

Full Protocol:

• Slide preparation
• • Mount 2,5 µm FFPE tissue sections on superfrost slides.
  • Deparaffinize tissue sections 3x 5 min in xylene.
  • Rehydrate tissue sections in a descending ethanol series for 1 min each 100%, 96%, and 80% ethanol.
  • Rinse tissue sections for 5 min in TBST buffer (DAKO, K8000).
• Epitope retrieval
• • Autoclave tissue sections for 5 min at 121 °C in 1x Tris-EDTA-citrate buffer pH7.8 (20x Tris-EDTA-citrate buffer stock solution: 5 g Trizma base (Sigma-Aldrich, T1503), 10 g EDTA (Merck, 1.08418), 6.4g tri-sodium citrate (Sigma-Aldrich, C0909), adjust to pH 7.8 using HCL 1 M, ad 1 L with dH₂O).
  • Rinse tissue sections for 5 min in TBST buffer.
• Peroxidase blocking
• • Incubate tissue sections for 10 min in Peroxidase-Blocking Solution (Dako REAL, S2023).
  • Rinse tissue sections 2x for 5 min in TBST buffer.
• Antibody incubation
• • Dilute primary rabbit anti-collagen IV antibody (antibodies-online, ABIN5596835, lot 48011) diluted 1:100, 1:200, or 1:300 in antibody diluent (Dako REAL, S2022).
  • Cover tissue section with 100-200 µl diluted antibody.
  • Incubate tissue sections for 1 h at 37 °C in a moist chamber.
  • Rinse tissue sections for 5 min in TBST buffer.
  • Apply EnVision Polymer-HRP mouse/rabbit Kit (Dako REAL, K5007) according to manufacturer’s recommendation.
  • Rinse tissue sections 2x for 5 min in TBST buffer.
• Staining
• • Cover slides for 10 min with DAB-Chromogen (EnVision Polymer-HRP mouse/rabbit Kit, Dako REAL, K5007).
  • Wash slides thoroughly with dH₂O.
  • Counterstain for 15 sec with Hematoxylin (Mayers Hematoxylin: 200ml ddH₂O, 0,2g Hematoxylin (Serva, 24420.02), 10 g aluminium potassium sulfate dodecahydrate (Merck, 1.01047), 0,04 g sodium iodate (Merck, 1.06525), 10 g chloral hydrate (Sigma-Aldrich, 15307)).
  • Develop for 15 sec in H₂O.
  • Dehydrate tissue sections in an ascending ethanol series for 1 min each 80%, 96%, 100% ethanol.
  • Wash tissue sectiona 3x 5 min in xylene.
  • Apply mounting medium and coverslips.
• Image acquisition
• • o Acquire images using a Galileo TMAtic (ISENET).

Experimental Notes:

• For antibody comparison an antibody test TMA was used that contained 80 normal tissues from 21 different organs and 95 neoplastic tissues from 18 different tumor types. Despite some cytoplasmic and stromal background ABIN5596819 identified identical structures as the reference antibody MSVA-704R. An additional occasional staining of nuclei which was only seen by ABIN5596819 must be considered a cross-reactivity.

• According to the rather ubiquitous nature of collagen IV expression, orthogonal validation is not optimally suited for the validation of collagen I antibodies. In agreement with RNA screening studies, including the Human Protein Atlas (HPA) RNA-seq tissue dataset, the FANTOM5 project, and the Genotype-Tissue Expression (GTEx) project (all summarized in https://www.proteinatlas.org/ENSG00000134871-COL4A2/tissue), collagen IV staining by ABIN5596819 was particularly high in the placenta, colon, smooth muscle, and the lung. These are among the tissues with the highest recorded RNA expression.

Handling

Format: Liquid

Concentration: 1.0 mg/mL

Buffer:

Buffer: 0.125 M Sodium Borate, 0.075 M Sodium Chloride, 0.005 M EDTA, pH 8.0

Stabilizer: None

Preservative: Sodium azide

Precaution of Use: This product contains Sodium azide: a POISONOUS AND HAZARDOUS SUBSTANCE which should be handled by trained staff only.

Storage: 4 °C,-20 °C

Storage Comment: Store vial at 4° C prior to opening. This product is stable at 4° C as an undiluted liquid. Dilute only prior to immediate use. For extended storage, mix with an equal volume of glycerol, aliquot contents and freeze at -20° C or below. Avoid cycles of freezing and thawing.

Expiry Date: 12 months

References for anti-Collagen IV antibody (ABIN5596835)

Ida, Hikage, Itoh, Ida, Ohguro: "Prostaglandin F2α agonist-induced suppression of 3T3-L1 cell adipogenesis affects spatial formation of extra-cellular matrix." in: Scientific reports, Vol. 10, Issue 1, pp. 7958, (2020) (PubMed).

Kumar Gupta, Sarkar, Wertheim, Pan, Carroll, Oxburgh: "Asynchronous mixing of kidney progenitor cells potentiates nephrogenesis in organoids." in: Communications biology, Vol. 3, Issue 1, pp. 231, (2020) (PubMed).

Hwang, Huang, Burwell, Peterson, Connor, Weiss, Yu, Li: "In Situ Imaging of Tissue Remodeling with Collagen Hybridizing Peptides." in: ACS nano, Vol. 11, Issue 10, pp. 9825-9835, (2019) (PubMed).

Tanaka, Ng, Yang Yu, Casco-Robles, Maruo, Tsonis, Chiba: "A developmentally regulated switch from stem cells to dedifferentiation for limb muscle regeneration in newts." in: Nature communications, Vol. 7, pp. 11069, (2016) (PubMed).

Fetting, Guay, Karolak, Iozzo, Adams, Maridas, Brown, Oxburgh: "FOXD1 promotes nephron progenitor differentiation by repressing decorin in the embryonic kidney." in: Development (Cambridge, England), Vol. 141, Issue 1, pp. 17-27, (2014) (PubMed).

Seifert, Kiama, Seifert, Goheen, Palmer, Maden: "Skin shedding and tissue regeneration in African spiny mice (Acomys)." in: Nature, Vol. 489, Issue 7417, pp. 561-5, (2012) (PubMed).

Seifert, Monaghan, Voss, Maden: "Skin regeneration in adult axolotls: a blueprint for scar-free healing in vertebrates." in: PLoS ONE, Vol. 7, Issue 4, pp. e32875, (2012) (PubMed).

Pinheiro, Ferreira, Kitten, da Silveira, da Silva, Santos, Gava, Castro, Magalhães, da Mota, Botelho-Santos, Bader, Alenina, Santos, Simoes E Silva: "Genetic deletion of the angiotensin-(1-7) receptor Mas leads to glomerular hyperfiltration and microalbuminuria." in: Kidney international, Vol. 75, Issue 11, pp. 1184-1193, (2009) (PubMed).

Target Details for Collagen IV

Target: Collagen IV (COL4) (Collagen, Type IV (COL4))

Alternative Name: Collagen Type IV (COL4 Products)

Synonyms: collagen, type IV antibody, Let-2 antibody

Background:

Synonyms: Arresten antibody, Canstatin antibody, Collagen Of Basement Membrane Alpha 1 Chain antibody

Background: Rockland produces highly active antibodies and conjugates to collagens. Collagens are highly conserved throughout evolution and are characterized by an uninterrupted ''Glycine-X-Y'' triplet repeat that is a necessary part of the triple helical structure. For these reasons, it is often extremely difficult to generate antibodies with specificities to collagens. The development of 'type' specific antibodies is dependent on NON-DENATURED three-dimensional epitopes. Rockland extensively purifies collagens for immunization from human and bovine placenta and cartilage by limited pepsin digestion and selective salt precipitation. This preparation results in a native conformation of the protein. Antibodies are isolated from rabbit antiserum and are extensively cross-adsorbed by immunoaffinity purification to produce 'type' specific antibodies. Greatly diminished reactivity and selectivity of these antibodies will result if denaturing and reducing conditions are used for SDS-PAGE and immunoblotting.

Gene Name: COL4A1

Gene ID: 1282

UniProt: P02462
